LS VISION LS-CS102-4G-50X Telecamera di sicurezza alimentata ad energia solare da 26W 4G AOV con registrazione 24/7 ore su 24.
LS VISION: A global leader in AOV solar-powered outdoor cameras, delivering reliable wireless security solutions.
AOV (Always on Video): Enjoy 24/7 continuous recording with AOV camera monitor system—full-frame video when motion is detected, low-frame recording when idle.
50x zoom monitor 1000-2000M in the daytime and 200M at night
Top technology in solar camera
| Peso | 6 kg |
|---|---|
| Dimensioni | 37 × 24 × 31 cm |
Key Features
- 2K dual-lens dual-screen AOV 4G solar powered battery PTZ camera
- Pan&Tilt: Pan 355 degree&Tilt 100 degree
- 26 watt dual solar panel with 1.8m extension cord,built-in 31200mAh batteries
- Citofono bidirezionale
- Cloud storage and TF card storage maximum 512G（without TF card）
- 4G network, remote viewing/playback via APP (ICsee)
- Ai humanoid detection alarm and real-time push of alarm information, detection distance: within 80 meters
- È possibile impostare un tempo di armamento arbitrario e un suono di allarme.
- 4mm wide-angle lens + 6~108mm 50x zoom lens,built-in infrared light + white light, IR distance 100 meters
- 24/7 Surveillance Recording, it can work for 3 to 7 days when fully charged
- Always on video (AOV), low frame rate recording during standby time and full-frame recording after humanoid detection is triggered
- Supporto del tracciamento automatico degli umanoidi
- Grado di impermeabilità IP66
LS VISION LS-CS102-50X 24/7 Hours Recording 26W 4G AOV Solar Powered Security Camera
LS VISION, a global leader in AOV solar-powered outdoor cameras, presents the LS-CS102-50X security camera, delivering reliable and continuous wireless monitoring for outdoor security. This cutting-edge AOV solar powered wireless security camera offers full-frame video recording when motion is detected, with low-frame recording when idle, ensuring 24/7 monitoring with unparalleled performance.
Why Choose LS VISION LS-CS102?
VISIONE LS, a leading supplier of solar-powered 4G CCTV cameras, has earned a global reputation for reliability and innovation. Founded in 2010 in Shenzhen, China, LS VISION quickly became one of the top brands for 4G outdoor CCTV cameras, gaining trust worldwide with over 100 million customers across more than 100 countries.
Our LS-CS102 model is equipped with advanced technology, designed to provide high-definition video surveillance and energy-efficient monitoring for both residential and commercial applications. The dual-lens design ensures excellent image quality across wide areas and detailed close-ups, making it ideal for large properties, farms, construction sites, and remote locations with limited power and internet access.
Innovative Technology
The LS-CS102 comes with advanced dual-lens technology, offering a 2.5mm wide-angle lens for a broad view and a 5-50mm optical zoom lens for detailed monitoring from both near and far.
This feature ensures that you can capture both large-scale scenes and specific details clearly, making it ideal for various outdoor applications.
Main Advantages of Dual Lens Technology
The LS-CS102 uses state-of-the-art dual lens technology, with both lenses offering 4MP resolution. The first lens has a 135° wide-angle view, while the second lens features PTZ functionality for fine-tuned surveillance.
This configuration allows the camera to cover more area and capture more details compared to traditional monocular cameras.Whether monitoring broad landscapes or specific objects, the LS-CS102 provides a comprehensive view with high clarity.
With features like Pan 355° & Tilt 90°, the LS-CS102 can monitor areas in two directions using a single long range surveillance camera, reducing the number of units required and saving on both installation and equipment costs.
This flexibility, combined with the 24/7 recording security camera’s solar-powered efficiency, makes it a cost-effective choice for both residential and commercial security needs.
AOV Solar Cameras vs. PIR Solar Cameras: A New Standard in Surveillance
While PIR (Passive Infrared) solar cameras detect motion to record, AOV Solar Cameras offer a higher level of security by recording videos at all times. The feature guarantees that you will miss nothing and your property will be under watch 24/7.
Moreover, AOV Solar Cameras are specially designed for longer battery life as it runs on solar energy which makes them more effective and efficient than the PIR cameras. By making these improvements, companies may customize the security solution for their needs.
Motion Detection & Alarm
The LS-CS102 camera integrates PIR sensors with humanoid detection to ensure that only human movements trigger recording. This helps minimize irrelevant video recordings and false notifications. Once a human is detected, it activates the camera, starts recording, and sends an instant alert to your mobile device. This technology significantly improves the protection of your property and provides timely responses to potential threats.
The remote control camera also supports motion detection alarm notifications, which push alerts to your mobile phone when motion is detected. If enabled, the camera’s LED floodlight can also turn on to illuminate the area and enhance visibility during the detection event.
Motion Detection Technology – PIR + Humanoid Detection
The LS-CS102 camera supports 24/7 recording with motion detection recording, making it more energy-efficient than traditional IP cameras. It activates only when motion is detected, saving power and storage. The PIR (Passive Infrared) sensors provide accurate detection of human movement, while the humanoid detection feature reduces false positives caused by animals or non-human movements. This system enhances security by focusing on the most relevant events.
At LS VISION, we’re committed to providing innovative and sustainable solutions that redefine the way you protect your home or business. Let’s explore the capabilities of our 4G CCTV cameras and revolutionize your security setup.
How to Choose a 4G CCTV Camera Based on Your Country's 4G Frequency Bands
It’s essential to select a 4G CCTV camera that supports the frequency bands used by local mobile networks. The LS-CS102 model is compatible with multiple 4G frequency bands, ensuring that it can be used in various regions worldwide.
Frequency Bands Supported:
- Europe Version:LTE FDD: B1/B3/B7/B8/B20, WCDMA: B1/B8
- America Version:LTE FDD: B2/B4/B12, WCDMA: B2/B4/B5
- Australia Version:LTE FDD: B1/B2/B3/B4/B5/B7/B8/B28, LTE TDD: B40, WCDMA: B1/B2/B5/B8
Transmission Data:
- LTE FDD:Max 10Mbps (DL), Max 5Mbps (UL)
- LTE TDD:Max 8.96Mbps (DL), Max 3.1Mbps (UL)
- HSPA+:Max 42Mbps (DL), Max 5.76Mbps (UL)
- UMTS:Max 384Kbps (DL), Max 384Kbps (UL)
Applications:
Farm & Orchard Monitoring
Ideal for large outdoor spaces, such as farms and orchards, where traditional surveillance methods are impractical.
Remote Area Surveillance
Perfect for areas with no internet or power access, including forests, reservoirs, or rural properties.
Construction Site Security
Provides round-the-clock surveillance for construction sites, ensuring secure and constant monitoring of ongoing projects.
General Outdoor Surveillance
Use for home security, monitoring warehouses, or any outdoor spaces requiring reliable, all-weather protection.
Simple Installation & Cost Savings
Unlike traditional CCTV systems that require complex installation and costly professional assistance, the LS-CS102 is designed for easy setup and minimal maintenance. Its solar-powered design reduces ongoing energy costs, and the camera can be installed in virtually any outdoor location without the need for external power sources.
| Modello NO. | LS-CS102-4G-50X |
| Camera | |
| Image Sensor | 1/3″ CMOS 2MP |
| Solution | RV1106G2+SC2236P |
| Otturatore | 1/50(1/60)s ~ 1/10000s |
| Mini Illumination | Color: 0.01Lux @(F1.2,AGC ON);0 Lux with IR;
Black & White:0.001 Lux @ (F1.2,AGC ON) 0 Lux with IR |
| Digital Noise Reduction | 2D and 3D DNR |
| Stinking Settings | 50HZ/60HZ |
| Network Standard | 4G LTE |
| 4G Frequency Band | LTE-FDD：B1/B3/B5/B8 LTE-TDD：B34/B38/B39/B40/B41 |
| Operating Mode | Electricity Model, Performance Mode, Custom Mode |
| Lente | |
| Lens Focal Length | 6~108mm
50X zoom
|
| Aperture | F2.57 ~ F3.85 ±5% |
| Field of View | Wide: Diagonal 59.36° Horizontal: 52.12° Vertical:29.75°
Tele: Diagonal 3.84° Horizontal: 3.36° Vertical: 1.9° |
| Video | |
| Streaming | Main streaming, sub-streaming |
| Image Output | 1920*2160@12fps; 800*896@12fps |
| Battery Power Display | Supporto |
| Audio | |
| Two-way Audio | Supporto |
| Immagazzinamento | |
| Immagazzinamento | TF card (max 512G) |
| Port | |
| Audio | Built in microphone and speaker |
| 4G Port | 4G antenna interface |
| Factory Data Reset | Supporto |
| Intelligent Function | |
| Allarme | humanoid detection |
| Distanza di rilevamento | 80 meters |
| Accuracy | AI algorithm, accuracy rate up to 99.9% |
| Remote Control | |
| APP | APP: ICSEE |
| Light | |
| Light Mode | IR Night Vision/ Intelligent Night Vision/ Full Color Night Vision |
| Warm Light Distance | Up to 60m |
| IR Light Distance | Up to 80m |
| LEDS | 6pcs Dual Wicks LED
4pcs IR LED+2 Laser LED+ 4pcs Warm light LED |
| PTZ Control | |
| Rotation Range | Pan：0- 270º Tilt：0- 90 º |
| Rotation Speed | Pan：20°/s Tilt：10°/s |
| Generale | |
| Power Supply | 5V battery power supply, solar charging; |
| Pannello solare | 26W ; Output voltage 5V |
| Power Connector | TYPE-C |
| Capacità della batteria | 31200mAh |
| Operating Conditions | -20℃ ~ 50℃; humidity less than 95% |
| Factory Data Reset | Supporto |
| Material | Metal |
| Weather Proof Rating | IP66 |
| Dimension | Packaging: 365*230*310mm,5.2kg |
