LS VISION LS-AOV01-4G HiEasy 4K AOV Solar 4-Lens 24/7 Recording Cloud Storage Intelligent Camera
· LS VISION – AOV Solar Camera Pioneer
Powered by the HiEasy chip, LS-AOV01-4G is our latest 4G solar camera with 24/7 AOV recording and true quad-lens innovation.
· 4 Lenses. 4 Screens. True Advantage
Exclusive quad-lens design with AI ISP delivers sharp, balanced images — a rare offering with almost no direct competition.
· Two Models. One Mission: Zero Blind Spots
AOV version saves power with low-frame standby and full-frame on detection. Constant-power version records full-frame 24/7 — both ensure full coverage.
· Built to Scale for Global Dealers
No SIM card setup needed. Plug-and-play across multiple countries with OEM-ready support for local branding.
· B2B Ready for the Next Market Wave
AOV camera adoption is rising — secure early mover advantage with a differentiated, high-margin product.
| Units per Carton | 1 |
|---|---|
| Carton Dimensions (mm) | 270*270*190 |
| Carton Weight (kg) | 2.5 |
Wesentliche Merkmale
- 4K four-lens four-screen AOV 4G solar powered battery PTZ camera
- Schwenken/Neigen:Schwenken 355 Grad/Neigen 100 Grad
- The left and right cameras support 270° pan rotation (manual) and 90° tilt adjustment (manual)
- 15 watt dual solar panel with 2m extension cord,built-in 16000mAh batteries
- Zwei-Wege-Sprechanlage
- Cloud storage and TF card storage maximum 256G（without TF card）
- 4G network, remote viewing/playback via APP (HiEasy)
- Ai humanoid detection alarm and real-time push of alarm information, detection distance: within 30 meters
- 4mm +4mm+4mm+6mm lens,16X digital zoom,built-in infrared light + white light, IR distance 50 meters
- 24/7 Surveillance Recording, it can work for 5 to 7 days when fully charged
- Always on video (AOV), low frame rate recording during standby time and full-frame recording after humanoid detection is triggered
- Unterstützung der automatischen Verfolgung von Humanoiden
- Built-in cloud SIM, factory standard 100M 4G data
- Wasserdicht nach IP66
LS VISION LS-AOV01-4G HiEasy 4K AOV Solar 4-Lens 24/7 Recording Cloud Storage Intelligent Camera
LS VISION, a global leader in AOV (Always on Video) solar-powered security cameras, introduces the LS-AOV01-4G HiEasy Camera. Designed for unmatched performance and reliability, this camera provides 24/7 surveillance and is fully powered by solar energy, making it the ideal choice for security in remote locations or areas without reliable power sources.
The LS-AOV01-4G is perfect for both residential and commercial applications, providing round-the-clock monitoring and intelligent cloud storage.
Die AOV-Solarkamera that records 24/7 ensures continuous monitoring without any interruptions. It captures full-frame video when motion is detected and switches to low-frame recording during standby.
With its solar-powered functionality, this camera provides uninterrupted security, making it ideal for remote locations. This system is perfect for both residential and commercial use, where constant surveillance is necessary without worrying about power outages.
Cloud Storage and Intelligent Features
This camera comes equipped with cloud storage intelligent camera capabilities, allowing footage to be securely stored and accessed remotely. You can easily manage and retrieve recordings from anywhere, ensuring that your data is always safe and within reach.
Whether you’re at home or on the go, this feature provides peace of mind knowing your footage is backed up and secure in the cloud.
Pan & Tilt Control for Full Surveillance
The HiEasy Camera allows for a versatile 0 to 355° horizontal pan and 0 to 100° vertical tilt. The left and right cameras feature a manual 270° pan and 90° tilt adjustment, while the central camera offers electric 355° pan and 100° tilt.
This flexibility ensures complete coverage, enabling you to monitor large areas and zoom in on specific details with precision. Whether for home or business security, this dynamic control eliminates blind spots and guarantees full surveillance, providing ultimate peace of mind.
Four Lens Four Screens For Wide Coverage
LS-AOV01 camera has four-lens. Each lens has 16X digital zoom, providing a detailed view of multiple areas at once.
The camera is designed to offer wide coverage with four screens, showing different perspectives of various outdoor scenarios, such as a vehicle passing by, a house, children playing, and a group of people sitting.
This setup allows comprehensive monitoring with clear, zoomed-in views, ensuring high surveillance coverage across different angles. It also comes with infrared LEDs for better visibility in low-light conditions.
Solar Power Camera System for Continuous Operation
Featuring a 15W dual solar panel and 16,000mAh battery, the LS-HS10-4G ensures continuous operation without the need for external power sources.
The AOV solar camera that records 24/7 ensures constant monitoring, with minimal reliance on external electricity. This sustainable energy solution not only reduces costs but also makes it an eco-friendly option for whole year outdoor security.
4G Connectivity for Remote Viewing
The LS-AOV01 features a built-in 4G network module, allowing for seamless remote viewing and playback.
Through the HiEasy Camera app, users can access live footage and recorded data from anywhere, ensuring that security is always within reach. The 4G connectivity allows for real-time updates and constant surveillance, even in areas without a Wi-Fi connection.
AOV Camera: A Smarter Choice Over PIR Security Cameras
The AOV Low Power Camera provides 24-hour continuous recording with energy-efficient operation when no movement is detected. It seamlessly switches to full-frame recording upon detecting human motion, ensuring detailed footage is captured when needed.
In comparison, the PIR Low Power Camera only activates when motion is detected. It remains inactive during idle periods, recording only when movement is present, thus conserving energy.
While both cameras are designed to be energy-efficient, the AOV camera offers enhanced functionality by maintaining low-frame-rate recording during non-active periods, unlike the PIR camera that stays inactive until triggered.
PIR Motion Detection for Accurate Alerts
This LS-AOV01 4 Lens camera utilizes PIR humanoid detection to ensure that only human movement triggers recording and alerts.
This system minimizes false alarms and ensures that only relevant events are captured, providing more efficient surveillance and saving storage space. Whether it’s detecting an intruder or monitoring a specific area, this motion detection system provides accurate alerts every time.
Advanced Night Vision Technology
Equipped with built-in infrared and white light, the HiEasy Camera offers enhanced night vision capabilities.
Whether you need full-color night vision or infrared mode, it ensures clear and detailed images even in low-light conditions, offering reliable security 24/7. This feature ensures that your property remains under constant surveillance, even during the night, with no compromise on image quality.
Weatherproof Design for Outdoor Use
With an IP66 waterproof rating, the HiEasy Camera is designed to endure extreme weather conditions.
Whether it’s rain, snow, or intense heat, this AOV solar camera that records 24/7 performs reliably in any environment, making it perfect for year-round outdoor security. Its durable design ensures that the camera will continue to function effectively no matter the weather, keeping your property safe and secure.
TF Card Storage for Additional Storage Flexibility
The LS-AOV01-4G supports TF card storage up to 256GB, offering additional storage flexibility. This allows you to store a large amount of footage locally while still benefiting from the secure cloud storage intelligent camera system for remote access.
Whether you prefer cloud storage or local storage, this system offers a hybrid solution for all your surveillance needs.
Anwendungen
The LS-AOV01-4G 4 Lens camera provides reliable, 24/7 solar-powered surveillance. Its cloud storage intelligent camera features make it perfect for various applications, offering flexibility and security.
Home Security
Commercial Property Surveillance
Farm and Agricultural Monitoring
Remote and Off-Grid Locations
Construction Site Security
Outdoor Event Surveillance
The LS-AOV01-4G HiEasy Camera offers continuous solar-powered surveillance with its 4 Lens camera, providing clear, wide-angle coverage day and night.
Its cloud storage feature ensures easy, secure access to footage from anywhere. Enhance your security with the LS-AOV01-4G HiEasy Camera. Experience reliable, 24/7 surveillance and easy access to your footage. Get yours now and protect your property!
| Produkt | Modell Nr. | LS-AOV01-4G |
| Operating system | Embedded Linux operation system | |
| Hauptprozessor | H610 | |
| Sensor | Four pcs 1/3 CMOS Sensor | |
| lens | Fixed lens：4mm+4mm+4mm，Pan&tilt lens：6mm | |
| Video
| Video coding standard | H.265+ |
| System standard | PAL 50HZ/NTSC 60HZ | |
| Effective resolution | 8MP(1920*1080P*4) | |
| Video frame rate | Self-adaption | |
| Video stream | 135kbps-2048kbps | |
| Minimale Beleuchtungsstärke | Day mode 1Lux, night vision mode 0.01Lux | |
| Day and night mode | Auto | |
| Audio | Coding standard | G.711U |
| Audio input | Built-in microphone MIC | |
| Audio output | Built-in speaker | |
| Voice Call | With AI echo cancellation, support full-duplex voice calls | |
| Record management | Record mode | AOV recording and alarm recording |
| Record storage | TF card | |
| Cloud-Speicher | Support | |
| Alarm | Alarm detection | With 1T computing power, accurate human detection, detection distance up to 30 meters |
| Sound and light alarm | Support, when equipped with dual light board, supports sound and light alarm | |
| Alarm linkage | Video recording | |
| PTZ | Preset position | Support 6 preset position settings |
| Tracking Function | Support human tracking | |
| Night light | Night light function | Support night light function |
| 4G network | Frequenzbereich | Asia-pacific version:B1/B3/B5/B8/B34/B38/B39/B40/B41 European version:B1/B3/B5/B7/B8/B20/B28 |
| SIM | Cloud SIM and Nano SIM | |
| APP | APP | HiEasy |
| Solar power supply | Solar-Ladegerät | 15 watt dual panel |
| Kapazität der Batterie | 16000mAh | |
| others | TF card capacity | Maximum support 256GB(Universal FAT32 format) |
| Charging voltage | Standard DC5V | |
| Maximum power | 3W ±10% | |
| Arbeitsumfeld | -20℃ — +55℃ | |
| Size | Packaging box size | |
| Größe des Kartons | ||
| Weight |
Datenblatt
